Centrifugal Disk 1000

Application – Automated Feeding & Material Handling Systems

This Ø1000 centrifugal disk is engineered for industrial automation lines, serving as a core feeding and separation component for electronic parts, automotive components, and precision assemblies.
Optimized for high-speed, continuous production environments requiring stable rotation, load capacity, and dimensional accuracy.

Material – SUS304 Stainless Steel (Corrosion-Resistant Structure)

Manufactured from SUS304 stainless steel (GB/T 3280-2015), ensuring durability under continuous operation.

• Yield strength: ≥205 MPa
• Tensile strength: ≥520 MPa
• Elongation: ≥40%
• Density: 7.93 g/cm³
• Thickness: 8.0 mm (±0.25 mm)

Provides excellent corrosion resistance, fatigue strength, and long-term stability for automation equipment.

Product Dimensions & Accuracy

• Size: Ø1059 mm × H283 mm
• Roundness: ≤0.5 mm
• Flatness: ≤0.35 mm/m
• Surface roughness: Ra ≤1.6 μm
• Standard: GB/T 1804-2000 (Grade m)

Ensures precise fit and stable operation in high-speed rotating systems.

Manufacturing Process – CNC Metal Spinning + Precision Finishing

Produced using large-diameter CNC metal spinning (CNC1650 platform) combined with precision machining.

Core Process:
Degreasing → passivation → leveling → CNC spinning → deburring → precision finishing → cleaning → inspection

Process Advantages:

• High concentricity for stable rotation
• Uniform wall thickness and structural balance
• Reduced internal stress for long-term durability
• Suitable for large-scale automated production

Precision Control – Dynamic Balance & Rotational Stability

• Full dimensional inspection (CMM verification)
• Wall thickness monitoring (±0.01 mm)
• Flatness and geometric accuracy control
• Dynamic balancing: ≤5 g·mm/kg

Ensures smooth operation at high rotational speeds (≤2000 r/min) without vibration or instability.

Surface Condition – Industrial-Grade Finish

• Burr-free edges with chamfer (R ≥2.5 mm)
• Smooth surface (Ra ≤1.6 μm)
• Passivated for corrosion resistance
• Ready for direct integration into automation systems

Quality Control System (ISO 9001)

• Raw material spectroscopy (Cr ≥18%, Ni ≥8%)
• Ultrasonic testing (no internal defects)
• In-process inspection (≥97% conformity rate)
• Final inspection: AQL 2.5 standard
• Salt spray resistance ≥120 hours
• Full traceability with inspection reports

Performance Parameters (Automation Use)

• Rated speed: ≤2000 r/min
• Maximum load: ≤80 kg
• Operating temperature: -20°C to 200°C
• Environment: dry or light dust industrial workshops

Designed to withstand centrifugal force, friction load, and continuous operation cycles.

Production Capacity & Delivery

• Capacity: 15 pcs/day, 450 pcs/month
• Lead time: 12–18 days (standard), 18–25 days (bulk)
• Urgent orders: 8–10 days
• Packaging: anti-rust + foam + pallet (5 pcs/pallet)

Custom Engineering Capability

• Diameter range: Ø800–1500 mm
• Height range: 200–400 mm
• Optional materials: SUS316L / Q355B
• Custom design based on automation system parameters and operating speed

Application Scenarios

Widely used in:

• Automated feeding systems
• Electronic component sorting lines
• Automotive parts conveying systems
• Precision assembly production lines

Also applicable to:

• Rail transit component automation
• Ship equipment part handling
• New energy battery module production

Engineering Value (Why It Matters)

Compared with fabricated or welded disks, this solution provides:

• Higher rotational stability and balance
• Reduced vibration and noise in high-speed operation
• Improved lifespan under continuous load
• Better consistency for automated production lines

After-Sales & Technical Support

• 24-month warranty
• Free repair/replacement for quality issues
• Technical support for installation and system integration
• 24-hour response, solution within 1–3 days
• Long-term maintenance and dynamic balance calibration services
